Rodamiento de rodillos cónicos Timken 1985/1922, Diámetro exterior: 57.15 mm | Diámetro interior: 28.575 mm | Anchura: 19.355 mm
Tapered Roller Bearing Cup
Ver información técnicaReferencias
Timken:1985/1922
Rubix:798738793000
EAN:0053893663944
Resumen técnico
| Diámetro interior | 28.575 mm |
|---|---|
| Diámetro exterior | 57.15 mm |
| Anchura | 19.355 mm |
Detalles de producto : 1985/1922
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Cualidades
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Aplicaciones
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Información técnica
Atributos
| Dimensiones logísticas (lar. x an. x al.) | 15,875x57,15x57,15 mm |
|---|---|
| Peso neto | 75 g |
| Dimensiones del embalaje (lar. x an. x al.) | 26,924x60,452x60,452 mm |
| Diámetro interior | 28.575 mm |
| Diámetro exterior | 57.15 mm |
| Anchura | 19.355 mm |
| Peso | 0.23 kg |
| Serie | 1900 |
| Material | steel |
| Jaula | acero |
| Anchura de rodamiento total | 19.845 mm |
| Norma | iso 355 |
| Carga estática básica, radial - C0r | 50200 N |
| Carga dinámica básica, radial - Cr | 48400 N |
